Micral Titan Plus.

Greater milling distance in titanium machining.

Experience the application

105 m

instead of 75 m milling distancein the documented NOVA application comparison
FROM TOOL TO RESULT
Carbide end mill · Ø 10 mm

01 / The tool

Milling titanium.

A carbide cutter with Micral Titan Plus machines TiAl6V4.

Ø 10 mmTiAl6V4

02 / Engagement

Chip by chip.

The cutting edges mill a shoulder into the workpiece.

03 / The cutting edge

Contact at the cutting edge.

This is where chips, heat and mechanical loading meet the coating.

04 / The result

105 rather than 75 metres of milling distance.

Micral Titan Plus and the comparison coating in the documented trial.

05 / Your application

Your titanium machining.

Let’s discuss the tool, material and operating conditions.

Discuss your application
Technical data & application report
Tool
Carbide end mill · Ø 10 mm
Workpiece
TiAl6V4
Cutting speed vc
60 m/min
Radial engagement ae
5.0 mm
Axial cutting depth ap
10 mm
Comparison coating
Comp. AlCrN
Flank wear width according to the report
0.0125 mm
Original NOVA report: Micral Titan Plus 105 m, Comp. AlCrN 75 m, with machining data

The 3D view illustrates side milling engagement. Tool geometry, path and movement are schematic, not a reconstruction of the original trial to scale or in real time. The coating colour approximates the original photograph.
