Blasting & finishing
Prepare surfaces. Refine edges and coatings.
Wet and dry blasting prepare tool surfaces for coating. The blasting medium and intensity are matched to each surface.
NOVA Coating
Blasting for surface preparation.
Corrosion, EDM recast layers, compound layers and surfaces damaged by machining can impair coating adhesion. Defined blasting media and coordinated particle sizes and shapes help remove these residues.
- Microblasting using injector blasting
- Abrasive blasting using pressure blasting
- Cleaning, rust removal and microdeburring
- Usable equipment dimensions: 1,300 × 800 × 800 mm
Edge preparation & coating finishing.
Before coating
Drag and stream finishing provide targeted edge preparation. Before coating, cutting edges are rounded to suit the application.
- Drag & Stream Finish
- Defined cutting-edge radii
- Adapted to material and machining parameters
The required radius is defined according to your application and specifications.
After coating
A separate finishing treatment after coating can smooth the surface and support material flow.
- Reduced surface roughness
- Removal of droplets — small deposits on the coating surface
